Medical Scroll Air Compressor

GVA’s medical scroll air compressors feature completely oil-less technology, ensuring 100% oil-free air delivery. With minimal moving parts, they require less maintenance and offer a longer operating life. Additionally, their energy-efficient design provides more airflow while consuming less power, making them a reliable and cost-effective solution for various applications.

System Features

Single Point Connections for process air, electrical, and condensate drainage make installation straightforward.

ASME Certified Receivers come standard with a corrosion resistant epoxy lining.

Intuitive Touchscreen Controls will give you all the information you need for the system operation, service requirements, alarms, and more.

Integrated Aftercoolers and Water Separators ensure bulk liquid removal and appropriate air temperatures for optimized dryer functionality.

Multi Skid Systems with Quick Connections between each skid ensure each skid will fit through a standard doorway and make installation straightforward.

Remote monitoring, BMS communication, & ethernet connectivity allow you to monitor your system in the way that best suits your needs.

Medical Scroll Air Compressor Configurations

Model Number
Pump Motor Rating (HP)
Maximum Pressure (PSIG)
System capacity @ 50 psig (SCFM)
System capacity @ 50 psig (ICFM)
Receiver / Orientation
Spec Sheet
Duplex Stack
CC02D-XXM-08V
2
115
6.2
7.0
80 Gallon Vertical
CCXXD-XXM
CC03D-XXM-08V
3
115
9.0
10.2
80 Gallon Vertical
CC05D-XXM-08V
5
115
16.5
18.3
80 Gallon Vertical
CC07D-XXM-08V
7.5
115
23.0
25.5
80 Gallon Vertical
CC07D-XXM-12V
7.5
115
23.0
25.5
120 Gallon Vertical
CC10D-XXM-12V
10
115
31.5
34.0
120 Gallon Vertical
CC10D-XXM-20V
10
115
31.5
34.0
200 Gallon Vertical
CC10D-XXM-24V
10
115
31.5
34.0
240 Gallon Vertical
Triplex Stack
CC05T-XXM-12V
5
115
33.0
36.6
120 Gallon Vertical
CCXXT-XXM
CC05T-XXM-20V
5
115
33.0
36.6
200 Gallon Vertical
CC07T-XXM-12V
7.5
115
46.0
51.0
120 Gallon Vertical
CC07T-XXM-20V
7.5
115
46.0
51.0
200 Gallon Vertical
CC10T-XXM-20V
10
115
63.0
68.0
200 Gallon Vertical
CC10T-XXM-24V
10
115
63.0
68.0
240 Gallon Vertical
Quadruplex Stack
CC05Q-XXM-12V
5
115
49.5
54.9
120 Gallon Vertical
CCXXQ-XXM
CC05Q-XXM-20V
5
115
49.5
54.9
200 Gallon Vertical
CC07Q-XXM-20V
7.5
115
69.0
76.5
200 Gallon Vertical
CC07Q-XXM-24V
7.5
115
69.0
76.5
240 Gallon Vertical
CC10Q-XXM-20V
10
115
94.5
102.0
200 Gallon Vertical
CC10Q-XXM-24V
10
115
94.5
102.0
240 Gallon Vertical
Pentaplex Stack
CC05P-XXM-20V
5
115
66.0
73.2
200 Gallon Vertical
CCXXP-XXM
CC07P-XXM-20V
7.5
115
92.0
102.0
200 Gallon Vertical
CC07P-XXM-24V
7.5
115
92.0
102.0
240 Gallon Vertical
CC10P-XXM-20V
10
115
126.0
136.0
200 Gallon Vertical
CC10P-XXM-24V
10
115
126.0
136.0
240 Gallon Vertical
Hexaplex Stack
CC07H-XXM-20V
7.5
115
115.0
127.5
200 Gallon Vertical
CCXXH-XXM
CC07H-XXM-24V
7.5
115
115.0
127.5
240 Gallon Vertical
CC10H-XXM-20V
10
115
157.5
170.0
200 Gallon Vertical
CC10H-XXM-24V
10
115
157.5
170.0
240 Gallon Vertical

NFPA PLC Control Panel Including:

Need Help Picking the Best System for Your Application?

Our team of seasoned experts is dedicated to guiding you through the process of selecting the ideal system for your unique application. Additionally, with their wealth of knowledge and experience, they’ll carefully assess your requirements and provide tailored recommendations to ensure optimal performance and efficiency.
